FSP FlexGURU PRO 500W Power Supply Unit 24-pin ATX 1U
FSP FlexGURU PRO 500W Power Supply Unit 24-pin ATX 1U
- Brand:
- FSP
- Part number:
- PPA5008401
- EAN:
- 4713224522925
- New
- Available in 24/48 h
Shipping: €6.99 in Spain, €8.99 to the rest of the EU, free from €121 incl. VAT (€100 excl. VAT). Delivery in 24 h to 1 week depending on availability and address.
Description
Excellent Thermal Performance
The FlexGURU PRO series features a 40mm interior fan design, which reduces noise and allows for maximum cooling at all times.
Black Round Cables
The black round cables give your system a more sophisticated look compared to other entry-level power supplies.
90% Efficiency Conversion
Power supply efficiency directly affects your system's performance. The FlexGURU PRO 500W has a guaranteed typical efficiency of 90% and offers high conversion power to strengthen your system.
Multifunctional Design
The FlexGURU PRO series comes with an included 1U bracket that converts it into an industrial 1U power supply.
IEC 62368 Compliant
FSP Group provides you with the latest renewable energy technologies and offers a full range of additional safety features to keep up with the latest regulations. FSP has updated most power supplies to the latest IEC 62368 standard.
Safety Protection
OVP (Over Voltage Protection), UVP (Under Voltage Protection), OCP (Over Current Protection), OPP (Over Power Protection), SCP (Short Circuit Protection), and OTP (Over Temperature Protection). Full circuit protection to keep your hardware safe.
Japanese Electrolytic Capacitors
With Japanese electrolytic capacitors, the FlexGURU PRO series offers stable power and long-term reliability.
500W, Flex ATX, Active PFC, ATX 20+4, 4+4 PIN, SATA x 4, Molex x 2, Floppy
- Compatible with the latest Flex ATX V1.22
- Efficiency ≧ 90% at typical load
- 80 PLUS Gold Certification
- 1U bracket included for industrial systems
- Intelligent fan speed control
- Quiet and durable 40mm ball-bearing fan
- Black round cables for enthusiast needs
- Powerful single +12V rail
- Main Japanese electrolytic capacitors
- Ready for the latest Intel CPU
- Full protections: OCP, OVP, SCP, OPP, OTP
Specifications
| Power Control | |
|---|---|
| Total power | 500 W |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50 - 60 Hz |
| Input current | 8-4 A |
| Power Factor Correction (PFC) type | Active |
| Combined power (3.3V) | 90 W |
| Combined power (+5V) | 90 W |
| Maximum output current (+3.3V) | 14 A |
| Maximum output current (+12V) | 41 A |
| Maximum output current (+5V) | 16 A |
| Maximum output current (-12V) | 0.3 A |
| Maximum output current (+5Vsb) | 3 A |
| Efficiency | 90% |
| Power protection features | Over-current, Over-voltage, Over-power, Over-temperature, Short-circuit |
| Ports and Interfaces | |
| Motherboard power connector | 24-pin ATX |
| Number of SATA power connectors | 4 |
| Peripheral (Molex) power connectors (4-pin) | 2 |
| EPS power connector (8-pin) | Yes |
| PCI Express power connectors (6+2 pin) | 2 |
| CPU power connector (4+4 pin) | Yes |
| ATX power connector (24-pin) | Yes |
| Floppy power connector | 1 |
| Floppy drive connector | Yes |
| Cabling type | Non-modular |
| Performance | |
| 80 PLUS certification | 80 PLUS Gold |
| Use with | Storage Server/NAS |
| Power supply unit (PSU) form factor | 1U |
| Bearing technology | Ball bearing |
| Design | |
| Product color | Black |
| Cooling type | Active |
| Fan diameter | 4 cm |
| Number of fans | 1 fan(s) |
| Packaging content | |
| Cables included | CPU, PCIe, Peripheral (Molex), SATA |
| Weight and dimensions | |
| Width | 40.5 mm |
| Depth | 150 mm |
| Height | 81.5 mm |
| Logistics data | |
| Warranty period | 5 year(s) |
