StarTech.com SV565FXHD4KU KVM Extender Transmitter and Receiver
StarTech.com SV565FXHD4KU KVM Extender Transmitter and Receiver
- Brand:
- StarTech.com
- Part number:
- SV565FXHD4KU
- EAN:
- 0065030887694
- New
- Available in 24/48 h
Shipping: €6.99 in Spain, €8.99 to the rest of the EU, free from €121 incl. VAT (€100 excl. VAT). Delivery in 24 h to 1 week depending on availability and address.
Manufacturer: StarTech.com Ltd., 45 Artisans Crescent, London, Ontario N5V 5E9, Canadá · www.startech.com
EU responsible person: StarTech.com Limited (entidad Europa), Celsiusweg 16, 5928 PR Venlo, Países Bajos. Tel. +31 (0)20 7006 073. Contacto: https://www.startech.com/en-eu/contact
Description
HDMI KVM Extender Kit | 4K 60Hz | 4:4:4 Chroma Subsampling | 2x SFP+ LC (Multimode) Included
This HDMI KVM extender kit lets you use a keyboard, mouse, and monitor to remotely control any computer over a point-to-point fiber connection. When paired with a KVM switch, the KVM console extender can be used with multiple computers. The extender features three USB HID ports that allow you to connect HID devices, such as your keyboard and mouse.
Supports UHD 4K 60Hz
The HDMI KVM extender delivers UHD image quality up to 4K 60Hz to your remote display with support for 4:4:4 chroma subsampling.
Hassle-Free Installation
The extender supports EDID pass-through, ensuring your computer can automatically configure optimal settings for your display using 10G LC multimode fiber cabling.
StarTech 4K Fiber HDMI KVM Extender - KVM Switch Console Extender with HDMI Video and Remote USB - up to 300m (Multimode) with 2x 10Gb SFP+ MMF Modules - (TX/RX) (SV565FXHD4KU)
- REMOTE ACCESS: The 4K HDMI and USB KVM extender over fiber controls a KVM switch/console or computer using a fiber optic cable at distances up to 300m (multimode cable) or 500m (singlemode cable). Open SFP+ slots
- 4K 60Hz VIDEO: The HDMI transmitter and receiver extender kit achieves UHD resolutions up to 3840 x 2160 at 60Hz, and supports 4:4:4 subsampling for accurate color and image in applications requiring high-resolution video
- DIGITAL AUDIO & HDMI 2.0: The keyboard, video, and mouse extender with EDID transfers display capabilities to the video source, maximizing compatibility. 7.1 audio over HDMI for high-quality sound. HDCP 2.2
- SPECIFICATIONS: HDMI 2.0 Fiber Optic KVM Extender / 3x USB 1.1 HID / OS Independent / EDID / Supports MM or SM SFP+ / 2x 10G multimode SFP+ incl. / LC / 300m (MM) or 500m (SM) max extension range / 2-year warranty
- EASY TO DEPLOY: Simple point-to-point setup using a standard fiber optic cable and included SFP+ modules. No proprietary software or network settings to configure. StarTech.com advisors are available 24/5
Specifications
| Features | |
|---|---|
| Type | Transmitter & receiver |
| Connectivity technology | Wired |
| Maximum transfer distance | 500 m |
| Rack mounting | No |
| Resolution (maximum digital) | 3840 x 2160 Pixels |
| Maximum refresh rate | 60 Hz |
| On Screen Display (OSD) | No |
| Product color | Black |
| Material | Metal |
| LED indicators | Power, Status |
| Transmitter | |
| Video transmitter port type | HDMI |
| Number of displays supported | 1 |
| Receiver | |
| Video local receiver port type | HDMI |
| Ports & interfaces | |
| USB 1.1 ports quantity | 3 |
| Power | |
| AC input voltage | 100 - 240 V |
| Input current | 0.3 A |
| AC adapter output voltage | 5 V |
| AC adapter output current | 2 A |
| Power consumption (transmitter) (max) | 10 W |
| Power consumption (receiver) (max) | 10 W |
| Weight & dimensions | |
| Transmitter width | 7.5 cm |
| Transmitter depth | 10 cm |
| Transmitter height | 2.8 cm |
| Transmitter weight | 450 g |
| Receiver width | 7.5 cm |
| Receiver depth | 10 cm |
| Receiver height | 2.8 cm |
| Receiver weight | 450 g |
| Packaging content | |
| Package width | 180 mm |
| Package depth | 310 mm |
| Package height | 74 mm |
| Package weight | 140 g |
| Packaging content | |
| AC adapter included | Yes |
| Cables included | Mini-USB |
| Quick start guide | Yes |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 50 °C |
| Storage temperature (T-T) | -10 - 60 °C |
| Operating relative humidity (H-H) | 0 - 80% |
| Other features | |
| Compliance certificates | CE, RoHS |
| Technical details | |
| Weight | 500 g |
| Logistics data | |
| Harmonized System (HS) code | 84733080 |
| Master (outer) case width | 405 mm |
| Master (outer) case length | 330 mm |
| Master (outer) case height | 265 mm |
| Quantity per master (outer) case | 6 pc(s) |
