Vertiv GXT5-3000IRT2UXL UPS (rack mount / external) AC 230 V
€1.774,99
€1.466,93 excl. VAT
· VAT 21 % included in the price
Skip to product information
Vertiv GXT5-3000IRT2UXL UPS (rack mount / external) AC 230 V
- Brand:
- Vertiv
- Part number:
- GXT5-3000IRT2UXL
- EAN:
- 0767041026580
- Model:
- GXT5
- New
- Available in 24/48 h
Shipping: €8.99 to Spain and the rest of the EU, free from €250 incl. VAT. Delivery in 24 h to 1 week depending on availability and address.
€1.774,99
€1.466,93 excl. VAT
· VAT 21 % included in the price
Manufacturer: Vertiv Group Corporation, 1050 Dearborn Drive, Columbus, OH 43085, Estados Unidos · www.vertiv.com
EU responsible person: Vertiv S.r.l., Via Leonardo da Vinci 16/18, 35028 Piove di Sacco (PD), Italia
Description
UPS (rack mount / external) - AC 230 V - 3000 Watts - 3000 VA - Lead acid - RS-232, USB - output connectors: 7 - 2U
Specifications
| Features | |
|---|---|
| UPS topology | Double-conversion (online) |
| Output power capacity (VA) | 3 kVA |
| Output power | 3000 W |
| Waveform | Pure sine wave |
| Operating input voltage (min) | 115 V |
| Operating input voltage (max) | 288 V |
| Input frequency | 50/60 Hz |
| Output operating voltage (max) | 240 V |
| Output frequency | 50/60 Hz |
| Output voltage regulation | 3% |
| Response time | 0 ms |
| Number of input phases | 1 |
| Number of output phases | 1 |
| Efficiency | 95% |
| Efficiency (online mode) | 95% |
| Efficiency (ECO mode) | 98% |
| Input power factor | 0.99 |
| Emergency Power Off | Yes |
| Noise level | 58 dB |
| Power protection features | Overload |
| Audible alarm(s) | Yes |
| Ports & interfaces | |
| AC outlet types | C13 coupler, C19 coupler |
| Number of AC outlets | 7 AC outlets |
| USB port | Yes |
| Serial interface type | RS-232, RS-485 |
| Serial port | 1 |
| Battery | |
| Battery technology | Sealed Lead Acid (VRLA) |
| Battery capacity | 9 VAh |
| Battery voltage | 12 V |
| Typical backup time at full load | 3 min |
| Typical backup time at half load | 9 min |
| Battery recharge time | 3 h |
| Hot-swappable battery | Yes |
| Design | |
| Form factor | Rackmount/Tower |
| Product color | Black |
| Display type | LCD |
| International Protection (IP) code | IP20 |
| Environmental conditions | |
| Operating temperature range | 0 - 40 °C |
| Storage temperature range | -15 - 40 °C |
| Operating relative humidity range | 0 - 95% |
| Storage relative humidity range | 0 - 95% |
| Operating altitude | 0 - 3000 m |
| Regulatory approvals | |
| Compliance certificates | RoHS |
| Certification | IEC/EN/AS 62040-2 2nd Ed (Cat 2 – 6); FCC 15 A CISPR22 A(RFI) |
| Safety regulation & standards | |
| Safety | IEC62040-1:2008, GS; UL1778, c-UL |
| Sustainability | |
| Sustainability certificates | ENERGY STAR |
| Weight & dimensions | |
| Width | 430 mm |
| Depth | 540 mm |
| Height | 85 mm |
| Weight | 28.2 kg |
| Packaging | |
| Package width | 517 mm |
| Package depth | 617 mm |
| Package height | 262 mm |
| Package weight | 33 g |
| Logistics data | |
| Harmonized System (HS) code | 85078000 |
| Other features | |
| Battery type | VRLA |
| Output connections | IEC320 C13 & C19 |
| Input connection type | C20 |
| Nominal output voltage | 230 V |
| Nominal input voltage | 230 V |
| Non-operating relative humidity (non-condensing) | 0 - 95% |
| Overload protection | Yes |
| Bypass | Yes |
