Viewsonic CDE8630 Signage Display Flat Panel for Signage
€3.487,99
€2.882,64 excl. VAT
· VAT 21 % included in the price
Skip to product information
Viewsonic CDE8630 Signage Display Flat Panel for Signage
- Brand:
- ViewSonic
- Part number:
- CDE8630
- EAN:
- 0766907017502
- New
- Available in 24/48 h
Shipping: €6.99 in Spain, €8.99 to the rest of the EU, free from €121 incl. VAT (€100 excl. VAT). Delivery in 24 h to 1 week depending on availability and address.
€3.487,99
€2.882,64 excl. VAT
· VAT 21 % included in the price
Manufacturer: ViewSonic Netherlands B.V., Haaksbergweg 75, 1101 BR Amsterdam, Países Bajos · www.viewsonic.com
Description
- Indoor Digital signage flat panel Black
- 2.18 m (86") 3840 x 2160 pixels LCD 450 cd/m²
- Direct-LED 60 Hz 8 ms
- Ethernet
- Built-in speakers 20 W
Specifications
| Display | |
|---|---|
| Display type | ADS |
| LED backlighting type | Direct-LED |
| Display diagonal | 2.18 m (86") |
| Display technology | LCD |
| Display resolution | 3840 x 2160 pixels |
| Display brightness | 450 cd/m² |
| HD type | 4K Ultra HD |
| Touchscreen | No |
| Native aspect ratio | 16:9 |
| Response time | 8 ms |
| Contrast ratio (typical) | 1200:1 |
| Contrast ratio (dynamic) | 5000:1 |
| Viewing angle, horizontal | 178° |
| Viewing angle, vertical | 178° |
| Display number of colors | 1.07 billion colors |
| Panel lifetime | 50000 h |
| Native refresh rate | 60 Hz |
| Haze rate | 25% |
| Surface hardness | 3H |
| Ports & interfaces | |
| HDMI ports quantity | 3 |
| HDMI version | 2.0/2.1 |
| HDMI input ports quantity | 2 |
| HDMI output ports quantity | 1 |
| DVI port | No |
| USB port | Yes |
| USB ports quantity | 3 |
| USB version | 2.0/3.2 Gen 1 (3.1 Gen 1) |
| USB connector | USB Type-A, USB Type-C |
| Ethernet LAN (RJ-45) ports | 1 |
| RS-232 | Yes |
| OPS module slot | Yes |
| Audio | |
| Built-in speaker(s) | Yes |
| Number of built-in speakers | 2 |
| RMS rated power | 20 W |
| Design | |
| Product design | Digital signage flat panel |
| Placement supported | Indoor |
| Orientation | Landscape/Portrait |
| Product color | Black |
| Screen shape | Flat |
| VESA mounting | Yes |
| Panel mounting interface | 800 x 400 mm |
| Bezel width (bottom) | 1.5 cm |
| Bezel width (side) | 1.5 cm |
| Bezel width (top) | 1.5 cm |
| Anti-glare screen | Yes |
| Mounting type | Wall |
| Performance | |
| Purpose | Universal |
| Operating hours (hours/days) | 24/7 |
| HDCP | Yes |
| HDCP version | 2.2 |
| Power | |
| Power consumption | 365 W |
| Power consumption (standby) | 0.5 W |
| Power consumption (max) | 510 W |
| Energy efficiency class (SDR) | G |
| Energy consumption (SDR) per 1000 hours | 318 kWh |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50 - 60 Hz |
| Energy efficiency scale | A to G |
| Computer system | |
| Computer system | Yes |
| Computer system type | System on Chip (SoC) |
| Processor built-in | Yes |
| Processor frequency | 1.5 GHz |
| Processor cores | 4 |
| Internal memory | 4 GB |
| On-board graphics adapter model | ARM Mali-G52 |
| Internal storage capacity | 32 GB |
| Operating system installed | Android 11 |
| Weight & dimensions | |
| Display width | 1930.8 mm |
| Display depth | 81.6 mm |
| Display height | 1101 mm |
| Display weight | 43.2 kg |
| Weight | 43.1 kg |
| Packaging data | |
| Package width | 2110 mm |
| Package depth | 225 mm |
| Package height | 1227 mm |
| Package weight | 60.8 kg |
| Packaging content | |
| Remote control included | Yes |
| Batteries included | Yes |
| Cables included | AC, HDMI, USB Type-C |
| Mounting kit | Yes |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 40 °C |
| Operating relative humidity (H-H) | 20 - 80% |
| Certificates | |
| Certification | cTUus, FCC, Energy Star 8.0, RoHS, Mexico NOM, Mexico Energy |
| Logistics data | |
| Quantity per pack | 5 pc(s) |
| Pallet length | 114 cm |
| Pallet width | 2.14 m |
| Pallet height | 135.6 cm |
| Harmonized System (HS) code | 8528521000 |
| Network | |
| Ethernet | Yes |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Wi-Fi | No |
| Technical details | |
| OPS slot | 1 |
| Other features | |
| Quick start guide | Yes |
